Perfect for certain use-cases
These are smaller horse power models that are ideally suited for use where flow rates are not huge. they are equally at home as solar pumps, with above-ground pools and as circulating pumps for heating systems. In each situation they provide just the quiet, reliable and efficient performance required.
Efficient by design
By eliminating reverse rotation of the impeller in high pressure situations, this ensures reliability, less energy and lower operating costs.
| Model No. | FX 140 | FX 190 | FX 250 | FX 340 | FX 520 |
|---|---|---|---|---|---|
| Equipment | |||||
| Horsepower | 0.50 HP | 0.75 HP | 1.00 HP | 1.50 HP | 2.00 HP |
| Voltage | 240 | 240 | 240 | 240 | 240 |
| Full Load Amps | 2.9 | 3.2 | 4.3 | 6.6 | 8.3 |
| Phase | Single | Single | Single | Single | Single |
| Input | 650 | 822 | 1015 | 1617 | 1900 |
| Full Load | 2.75 | 3.47 | 4.38 | 7.1 | 8.85 |
| Flow Rate @ 8 m/h | 140 lpm | 190 lpm | 250 lpm | 340 lpm | 520 lpm |
| Energy Consumption (kWh/Y) | 1068 | 1161 | 1296 | 1560 | N/A |
